| 產地 | 浙江 |
|---|---|
| 打印方向 | 雙向打印 |
| 售后服務 | 一年保修 |
| 執行質量標準 | 國標 |
| 自動化程度 | 全自動 |
| 經營模式 | 招商代理 |
| 適用工件 | 平面 |
| 品牌 | 遠贊 |
| 型號 | LM |
技術參數Technical parameter
| 設備機型Equipment type | LF | LM |
| 激光功率Laser power | 10-150W | 90W、100W |
| 激光類型Laser type | 進口10.6nmCO2激光器 imported 10.6nm CO2 laser | CO2封離式玻璃管激光器 CO2 sealed-off glass tube laser |
| 重復頻率Repetition rate | ≤50KHZ | |
| 打標范圍Marking range | 100*100~~300*300mm | |
| **小線寬Minimum line width | 0.22mm | 0.3mm |
| 標刻速度Marking speed | 0-7000mm/s | 0-2000mm/s |
| 支持格式Support format | AI、DST、DXF、BMP、PLT | |
| 工作電壓Working voltage | 220V±10% 50Hz（60Hz） | |
| 整機功率Power | ≤3KW（不含外置設備） | |
機型特點
l 標刻速度快，切割能力強，精度高，效果好。
l 進口射頻激光發生器，切割能力強，特別針對皮革打孔。
l 正版標刻機軟件，能實現圖形與文字的編輯功能。
l 采用紅光定位系統，使加工準確，不易產生廢料。
l 切割速度快，幅面大，能滿足高標準要求。
Type characteristics
l The marking speed is fast, the cutting ability is strong, theprecision is high, and the effect is good.
l imported RF laser generator has strong cutting ability, especiallyfor leather drilling.
The software of orthographic markingmachine can realize the editing function of graphics and text.
l Red light positioning system is adopted to make the processingaccurate and not easy to produce waste.
l The cutting speed is fast and the width is large, which can meet therequirements of high standards.
產品應用
l 皮革、布料、紙張、木制品、亞克力、水晶、陶瓷、大理石、復合材料等多種非金屬材料。
Product application
l Leather, cloth, paper, wood products, acrylic, crystal, ceramics,marble, composite materials and other non-metallic materials.
樣品Sample
