| 類型 | 高精高速等離子齒條機(jī) |
|---|---|
| 電流 | 交流 |
| 控制方式 | 數(shù)控 |
| 驅(qū)動形式 | 自動 |
| 用途 | 其它 |
| 頻段 | 高頻 |
| 品牌 | shinhu |
| 型號 | sc-3015 |
Model No. | Effective Cutting Scale |
SC-3013 | 3000mm*1300mm |
SC-3015 | 3000mm*1500mm |
SC-4020 | 4000mm*2000mm |
SC-6020 | 6000mm*2000mm |
Plasma generator | Stainless | Carbon steel | Galvanized Sheet | Aluminum | Copper | Basic iterms |
Chinese 63A | 0.3-5mm | 0.3-10mm | 0.3-5mm | 0.5-5mm | 0.2-6mm | Electricity and compressed |
Chinese 100A | 2-6mm | 2-15mm | 2-5mm | 2-8mm | 2-8mm | |
Hypertherm 45A | 0.3-3mm | 0.3-6mm | 0.3-5mm | 0.3-2mm | 0.3-2mm | |
Hypertherm 65A | 0.3-5mm | 0.3-12mm | 0.3-5mm | 0.3-6mm | 0.3-6mm | |
Hypertherm 100A | 1.5-8mm | 1.5-30mm | 1.5-5mm | 1.5-20mm | 1.5-15mm | |
Remark: No cutting slop for under 1mm thick; 3-5 degrees cutting slop for over 3mm thick. | ||||||
Main technical paremeters
Cutting mode | Plasma cutting |
Control system | Independent control stand, professional plasma cutting control system, high efficient anti-interference screening system |
Editing | Large storage, automatic |
Monitor | Optional with touch screen monitor |
Plasma generator | 40-100A, infinite variable adjustment, optional with different plasma generator model |
Anti-collision system | imported optical stop limit system, unique 360o protection |
Driving | import servo motor and high definition linear motion guide |
Deceleration | import planet deceleration technology |
Minimum running speed | 18000mm/min |
Cooling mode | With water spray cooling |
Thickness of material to cut | 0.2-15mm(depending on material and plasma generator power) |
Maximum torch lifting distance | 70mm |
THC mode | Professional arc-voltage automatic height control |
Electricity supply | 380v/50HZ/16A |
Continuous working time | 24 hours |
Net weight | about 1200 Kg |
Equipment characteristics
Thin metal cutting expert, high precision King speed | High quality thin metal cutting, high precision plasma cutting, first choice for high speed cutting |
Non-maintenance Plasma | Isolated control, super anti-interference ability against plasma |
Tiny slop Little dreg (Hypertherm Plasma) | Smooth cut surface, slop angle ≤5o Stable operation, almost non-maintenance in long term use High power converting efficiency, low processing cost |
Cutting irregular patterns Automatic height control | Advanced professional plasma system, rational design Arc-voltage control, quick response, 360o full protection for torch Flush bonding software, convenient control |
import driving parts Japanese servo motor Taiwanese motion guide | X/Y/Z axis high precision step motor, fast response, non maintenance Taiwanese linear motion guide, ensure high precision operation Main structure by jumbo CNC center, durably high precision German planet deceleration technology |
Convenient graphic an d text editing Automatic power failure protection Professional plasma control system | Large touch screen color monitor, human-machine interactive control system, USB interface, fast analogue import &export, PLC logic control, compatible with CorelDraw, AutoCAD etc. Windows operation system, cutting power adjusting, air pressure control, Cutting slot compensation, mechanical difference compensation etc. Continuous carving against power failure and breakpoint, Estimate of processing time, automatic tool aligning, real human-oriented design. Optional with automatic nesting software for material saving. |
Torch full protection Anti-collision system | Sensitive optical coupler, emergency halt before torch crashing 360o full protection for torch, avoiding accident |
Precise positioning Infra-red marking | Precise start point positioning to indicate Whole process monitoring on screen |
Easy to collect product Product selection design | Funnel shaped waste collector with trap valve, drawer collection Large ones on table; medium ones on trap valve; mini ones in drawer; easy to select an clean |
