●技術參數：                     ● Technical parameters:

   機器型號：CH–203–2                          Machine model: CH– 203 –2

   機器尺寸：L1250×W450×H1250mm        Machine size: L1250 x W450 x H1250mm

   UV燈參數：2KW×400mm×1支            UV lamp: 2KW *400mm* 1

   UV燈種類：紫外線高壓汞燈             UV lamp types: ultraviolet high pressure mercury lamp

   燈管強度：**                        Lamp intensity: **

   UV燈功率密度：100W/cm                The UV lamp power density: 100W/cm

   UV燈可調高度：100—170mm（可調）     UV lamp with adjustable height: 100 -170mm( adjustable)

輸送帶材質：特氟龍或不銹鋼             Conveyor belt material: Teflon or stainless steel

   輸送速度：0.1-10m/min                Transmission speed: 0.1-10m/min

   輸送帶寬度：300mm                    Belt width:300mm

   冷卻方式:強制風冷                    Cooling: forced air.

   自動延時關機：有                     Automatic delay shutdown:Yes

   外接電源：220V                       External power supply: 220V

●適應范圍：紫外線UV膠固化，油墨或者漆料固化

●Applicable scope: ultraviolet UV curing, ink or paint curin
